  • 2102N Tecna 20 kVA Linear Action Bench Pneumatic Operated Spot Welder w/ TE101 Processor
 Share this page on Facebook   Share this page on LinkedIn   Share this page on Twitter   Share this page on Whatsapp

Rapid Ref : 2102N

Tecna 20 kVA Linear Action Bench Pneumatic Operated Spot Welder w/ TE101 Processor 2102N

£5761.00  EX VAT
SSP Suggested Selling Price = £8230.00  YOU SAVE £2469.00
 Buy in 3 easy interest free payments of £1920.33† with
Please note, this product does not qualify for our standard shipping rates outside of the UK Mainland. Please contact us for shipping rates for this product.
  • Built-in compressed air filter unit
  • Lubrication-free pneumatic components to eliminate oil mist and to protect the environment
  • Chrome plated cylinder and stem for heavy duty works and long life, adjustable anti-rotation device
  • Water-cooled transformer, electrode holders, and electrodes; transformer with epoxy resin coated windings
  • Phase shift welding current adjustment. Synchronous SCR contactor insulated from cooling water circuit with protection thermostat
  • TE101 control unit
  • Two-stage electric foot control for clamping and welding pieces only if correctly positioned

Product Details

Nominal power @ 50%: 20 kVA

Maximum welding power: 60 kVA

No load secondary voltage: 4 V

Maximum short circuit current: 19 kVA

Maximum welding current on aluminium: 17.4 kA

Thermal current 100%: 3500 A

Supply voltage 50Hz: 400 V

Cables section L=30m: 25mm²

Delayed fuses: 63 A

Net weight (approximately): 81Kg
