Steelbeast XL-12 Bevelling Machine with 30° & 45° Angle Kit, 380 / 415v 3ph
BMXL12

The XL12 is a lightweight double-sided auto-feed plate bevelling machine capable of producing a double-sided weld prep. Weighing only 30Kg, the XL12 is an ultra-light option to create welding-ready bevels on a linear plate of any shearable material including Iron, Steel (up to 60Kg/mm2) and Stainless.

Features

• Produces a bevel edge ready for welding on any steel plate or component from 3 to 35mm thickness
• A minimum width of 60mm and a minimum working length of 60mm
• Can bevel angles 30°, 45°, 37.5°, 22.5° and 50° with additional kit
• Incredibly silent operation
• Can be used in a stationary position on a worktop, or automatically moves along the plate
• Cutters available for mild and stainless steel bevelling
• Easy setting of material thickness and cut with easily visible graduated scales for simple set-up
• Lightweight, operator-friendly handles for transferring the machine around the workplace or positioning during long machining processes
• High-quality and hard-performing working parts
• Electronic operating system enclosed in a safety-conscious, heavy-duty control box
